  • SX series Test Transformer Digital Display Operation Box/Console

    Adopting a new type of current relay, more precise and reliable, ensuring personal and equipment safety.Adopting a new type of time relay with a wider timing range.Monitoring and protection functions.

    Product Details of SX series Test Transformer Digital Display Operation Box/Console

    HTY_8054-2


    Product parameters:

    The SX series operation unit delivers a smoothly adjustable AC output voltage (0-250V) and incorporates comprehensive monitoring and protection features. Designed as dedicated support equipment for power testing, it operates alongside test transformers, converters, and other apparatus for electrical testing applications.

    HTY_8131-2

    Technical parameters:

    Input Voltage

    220V±10% 50Hz

    Tensión de salida

    0-250V/Output capacity: 5kVA

    Instrument voltage

    100V/100kV

    Rango de tiempo

    1S-99H

    Temperatura ambiente

    -20℃ to 50℃


    Característica:

    1.Monitoring: Output current, instrument voltage, zero position, contactor status (open/close), and timer status.

    2.Protection: Overcurrent protection with integrated timer relay.

    3.Enhanced Timing: Features a next-generation timer relay offering an extended timing range.

    4.Improved Safety: Utilizes a new, highly precise current relay for enhanced reliability, protecting personnel and equipment.

    5.Compact Design: Engineered for space efficiency with a small footprint and lightweight construction.


    precautions:

    1. During use, this instrument should be reliably grounded.

    2. The process of boosting and lowering should be carried out at a constant speed, without sudden acceleration or deceleration.

    3. During the experiment, monitoring instruments should be observed at all times to promptly detect any unexpected situations.

    4. During use, please handle the equipment gently and keep it clean and hygienic.
